PLEASE NOTE: Due to chip shortages, MS decoders are temporarily supplied with alternative chips. As a result, ZIMO is temporarily applying a surcharge! We have partially incorporated this in the sales price.

Dimensions 13.3 x 9.5 x 2.6 mm
Data format DCC, MM
Max. track voltage 35 V
Max. motor current 0.7 A
Peak current (approx. 20 sec) 1.5 A
Function outputs 4
Current limitation Function outputs 500 mA
Logic outputs 2 over SUSI, 2x Logic
LED output No
Servo output 2 over SUSI
SUSI Yes
Buffer capability Yes
Low output voltage No
Switching input No
Speaker output No
Audio No
Sound No
